ELEGOO OrangeStorm Giga 3D Printer

The ELEGOO OrangeStorm Giga is an industrial-grade 3D printer designed for extremely large projects. With its huge workspace and advanced features, this device is ideal for professionals who need a reliable tool for producing large format models. The OrangeStorm Giga opens up completely new possibilities in the fields of prototyping, architecture, industrial design and manufacturing, allowing the creation of parts that would require splitting into smaller pieces on other devices.

Maximum creative possibilities

If you need to print on a large scale, the OrangeStorm Giga is the perfect choice. With a working space of 800 x 800 x 1000 mm, it allows you to create life-size models and saves you the time of cutting your projects into smaller pieces. Just upload the template and let the printer do the work: a simpler and more efficient solution for large projects.

Fast and efficient platform heating

The OrangeStorm Giga heating platform consists of four independent PEI tiles, each measuring 410 x 410 mm. The entire surface can be uniformly heated to 100°C in just 17 minutes, allowing for a faster start of printing and ensuring better adhesion of the models to the platform. The ability to automatically identify and heat only the active part of the platform also allows significant energy savings.

Extreme print speed

The OrangeStorm Giga is equipped with a powerful 64-bit quad-core processor that provides the stability and processing power needed to make high-speed prints. With a maximum print speed of 300 mm/sec (with a recommended speed of 150 mm/sec), the OrangeStorm Giga is one of the fastest printers in its class, allowing you to significantly reduce delivery times for large projects.

Even more capacity

The OrangeStorm Giga supports printing using four nozzles at the same time. You can print four copies of the same model using different colors of filament or the same material in a single cycle. This functionality allows you to create multicolored models and increases production flexibility, especially useful in commercial and industrial applications.

Efficient cooling

The OrangeStorm Giga printer features powerful cooling fans on both sides of the frame to increase printing stability and accuracy. The intelligent control of the fans allows them to be turned off when printing is finished, reducing energy consumption and noise and extending the life of the device.

Reliable design and high-quality components

The OrangeStorm Giga is a 3D printer with a robust design equipped with linear guides on the X and Y axes, which increase printing stability and the precision of the head movement. The Z axis is equipped with an advanced steering mechanism that guarantees smooth and precise movement. In addition, a solid steel base and non-slip feet are used to ensure the stability of the device during operation.

Advanced printhead with automatic calibration

The OrangeStorm Giga printhead can reach a temperature of 300°C, allowing it to print with a variety of materials such as PLA, PETG, TPU and Nylon. The chromium-zirconium copper nozzle and 60W ceramic heater ensure a uniform and precise material flow, while the PID calibration function and automatic resonance compensation further improve print quality and stability.

inclusive

• OrangeStorm Giga 3D printer
• Printhead
• Screen
• Leveling plate x 2 pieces
• Toilet roll arm
• Toilet roll holder
• Filament break detector x 2 pieces
• Z axis guide cable lock
• Z axis limit switch x 2 pieces
• Assembled filament guide
• Roll holder module (5 kg)
• Power cable
• Leveling board
• Lube
• Profile corner x 8 pieces
• Tools
• Fasteners
• User manual
