THERMAL MASTER P3 Mini Thermal Camera for iOS/Android - Optimized for E-commerce

THERMAL MASTER P3: The Mini Professional Thermal Camera for iOS and Android

Discover the THERMAL MASTER P3, the professional-grade mini thermal camera, ideal for precision diagnostics of electronics, printed circuit boards (PCBs), electrical systems, industrial applications, HVAC, and household and automotive inspections. Thanks to the 256 × 192 pixel VoX sensor and the revolutionary X³IR™ technology, the image resolution is increased to 512 × 384 pixels, offering a clear and detailed view of the thermal distribution. The camera measures temperatures from -20°C to 600°C with an accuracy of ±2°C or ± 2% of the reading, and a thermal sensitivity (NETD) of less than 35 mK at 25°C makes it possible to detect even the smallest thermal differences. Despite its advanced capabilities, the P3 is incredibly compact: it measures only 59 × 27 × 17.2 mm, weighs 26.3 g and consumes just 0.32 W.

Precision PCB Diagnostics at the 1 mA Level

The P3 was developed with the analysis of printed circuit boards (PCBs) in mind, making it particularly suitable for applications where the rapid detection of micro-defects is crucial. The camera allows the testing of PCBs and the detection of leakage currents at the level of 1 mA, making it easy to identify problematic components without the need for lengthy checks on the entire circuit. The macro lens with manual focus allows precise image adjustment on small electronic components, and the 4.3 mm focal length supports close working. This makes the P3 an indispensable tool for service centers, electronic engineers, technicians and device repair professionals.

A Thermal Image that Reveals Unseen Details

X³IR™ technology increases image detail to 512 × 384 pixels, resulting in a sharper thermogram and simplified interpretation of the results. The Razor X™ algorithm offers an ultra-sharp image, while the Thermal Master high-sensitivity sensor core ensures precise mapping of temperature differences. A 25 Hz refresh rate provides a smooth preview during use, even when moving the camera over the analyzed area. You can also use the 15x digital zoom to take a closer look at specific parts of the image. The THERMAL MASTER P3 also offers 12 color palettes, including White Hot, Black Hot, Iron Red and Red Hot, as well as 8 other variations. This allows you to adapt the image display to specific tasks, surface types, or personal preferences. The camera allows you to adjust the emissivity, the correction of the distance and the setting of the ambient temperature, helping you to better adapt the measurement to the working conditions. These features are especially important when analyzing different materials and surfaces that may reflect or emit heat differently.

Wide Measurement Range for Demanding Applications

With a measurement range from -20°C to 600°C, the THERMAL MASTER P3 is suitable both for electronic diagnostics and for the inspection of plants, machinery, heating elements and industrial systems. The accuracy of ±2°C or ± 2% of the reading helps to ensure reliable results in daily service and inspection work. The camera supports alarms for high and low temperatures, making it easy to identify values outside the expected range. The isotherm function allows you to highlight a selected temperature range with a distinct color, speeding up the analysis of areas that require attention. The aircraft-grade alloy housing ensures strength while maintaining a lightweight design.

Smart Measurement and Convenient Data Analysis

The P3 offers advanced measurement tools that facilitate the analysis of different areas of the image. You can use 3-point, 3-line, 3-rectangle, and 3-circle measurements, as well as automatic tracking of central, maximum and minimum temperatures. IQ+ Precision Temp technology uses a dynamic temperature drift compensation algorithm and intelligent ambient temperature measurement to help maintain stability and accuracy of readings. A free offline professional data analysis is also available after taking a photo, useful for documenting defects and preparing reports.

Temp Master App and Multi-Device Support

The camera works with the Temp Master app, which can be downloaded from Google Play and the App Store. Supported devices include iPhone 8—16, smartphones running Android 7.0 and later, as well as iPads, Android smartphones, and computers. The PC software is available on the manufacturer's website, allowing you to work not only on mobile devices but also on larger screens. The P3 supports 12 languages, photo and video recording, and IR and PIP (picture-in-picture) modes.

Package Contents:

• Thermal camera
• Carry case
• USB-C to Lightning adapter
• Extension cable (50 cm)
• User manual
